Chevrolet Suburban XI (2007-2013) low speed gmlan serial data 3 4 Wiring diagram

3 9 LIN BUS LO SPD GMLAN SERIAL DATA 9 3 LO SPD GMLAN SERIAL DATA LIN BUS ASSIST STEP CONTROL MODULE (UNDER LEFT CENTER OF VEHICLE) AUDIO AMPLIFIER (IF EQUIPPED) (UNDER CENTER CONSOLE) BLK WIRE BLK/WHT WIRE DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH) DIGITAL RADIO RECEIVER DIGITAL RADIO RECEIVER (IF EQUIPPED) DK GRN WIRE DRIVER MEMORY SEAT MODULE (MSM) (UNDER DRIVER'S SEAT) GMLAN LOW SPEED HEATED SEAT CONTROL MODULE (IF EQUIPPED) HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) HVAC (LEFT END CONTROL END OF DASH) MODULE I/P FUSE BLOCK (LEFT END OF DASH) INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER DRIVER'S SEAT) INSIDE REARVIEW MIRROR (ISRVM) (W/ INTELLIGENT HIGH BEAM CONTROL) INSTRUMENT PANEL CLUSTER (IPC) LEFT I/P JUNCTION BLOCK (LEFT END OF DASH) LEFT SIDE OBJECT SENSOR (IF EQUIPPED) LIN BUS LOGIC DRIVER DOOR LOCK/ WINDOW SWITCH LOGIC DRIVER WINDOW MOTOR (DRIVER'S DOOR) LOGIC PASSENGER DOOR LOCK/ WINDOW SWITCH LOGIC PASSENGER WINDOW MOTOR (FRONT PASSENGER'S DOOR) LOW SPEED GMLAN LOW SPEED GMLAN SERIAL DATA LOW SPEED GMLAN SERIAL DATA 3 4 LTR FUSE 53 POWER DISTRIBUTION SYSTEM POWER LIFTGATE MODULE (IF EQUIPPED) (LEFT REAR OF CARGO AREA) RADIO REAR HEATED SEAT MODULE (UNDER LEFT REAR SEAT) REAR OBJECT SENSOR CONTROL MODULE (W/ REAR PARKING ASSIST) REAR SEAT AUDIO (RSA) CONTROL RED/WHT WIRE RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH) 5060 5060 RIGHT SIDE OBJECT SENSOR SERIAL DATA SPLICE PACK SPLICE PACK CADILLAC (LEFT END GMC/ OF DASH) CHEVROLET TAN WIRE TAN/BLK WIRE THEFT DETERRENT MODULE (TDM) (ON IGNITION SWITCH) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (CENTER OF DASH) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (IF EQUIPPED) (CENTER OF DASH) W/ LUXURY EDITION W/ RETRACTABLE POWER RUNNING BOARD W/O LUXURY ADITION W/O LUXURY EDITION W/O RETRACTABLE POWER RUNNING BOARD
