Chevrolet Suburban XI (2007-2013) l/gate pcb relay Wiring diagrams

This page contains all the electrical diagrams for the component. l/gate pcb relay, in which he is found in the car Chevrolet Suburban XI (2007-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram l/gate pcb relay (1 of 2)

Wiring diagram l/gate pcb relay for Chevrolet Suburban XI (2007-2013)

Get access

1 2 3 5704 6188 5706 ENDGATE RLY COIL L/GLASS CTRL ENDGATE RLY COIL 13 12 24 REAR SW OPEN SIG LIFTGATE AJAR SW L/GLASS SIG AIR BAG IGN FUSE 40 AUTOMATIC LEVEL CONTROL (ALC) RELAY (IF EQUIPPED) AUX HVAC-IGN FUSE 48 AUXILIARY MODE ACTUATOR AUXILIARY TEMPERATURE ACTUATOR BLK PNK/ WIRE BLK WIRE BLU LT WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) BREAKOUT TO HEADLIGHT SWITCH) BRN WIRE CHEVROLET/ GMC CADILLAC CHMSL PCB RELAY CLIMATE CONTROL SEAT MODULE (IF EQUIPPED) COMPUTER DATA LINES SYSTEM CONNECTOR ADAPTER DIGITAL VIDEO DISC (DVD) CONTROL MODULE INLINE FUSE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ECM-IGN FUSE 56 ELECTRONIC BRAKE CONTROL MODULE (EBCM) ENGINE CONTROL MODULE (ECM) FROM STUD 2 FUSE 63 (DIAGRAM 1 OF 8) FROM UNDERHOOD FUSE BLOCK (DIAGRAM 5 OF 8) FUEL PUMP FLOW CONTROL MODULE FUSE GMLAN SERIAL GRY WIRE HEATED STEERING WHEEL CONTROL MODULE HOT AT ALL TIMES FUSE HOLDER (ON POSITIVE BATTERY POST) HOT AT ALL TIMES I/P FUSE BLOCK RT STOP (LEFT END TURN OF DASH) FUSE HVAC-IGN FUSE 55 INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSIDE ELECTRONIC REARVIEW COMPASS MIRROR MODULE (ISRVM) INSTRUMENT PANEL CLUSTER (IPC) L/GATE PCB RELAY L/GATE RELSE FUSE 44 LEFT AIR TEMPE- RATURE ACTUATOR LEFT I/P JUNCTION BLOCK LIFTGATE HANDLE SWITCH LIFTGATE LATCH ASSEMBLY (CENTER OF LIFTGATE) LIFTGATE WINDOW LATCH ASSEMBLY LIFTGATE WINDOW LIFTGATE WINDOW AJAR SWITCH RELEASE ACTUATOR LIFTGATE WINDOW RELEASE SWITCH LOGIC LOGIC INSTRUMENT PANEL CLUSTER (IPC) LT BLU WIRE MISC IGN FUSE 43 SEO/ALC FUSE 54 MODE ACTUATOR NCA WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE REAR WINDOW WIPER MOTOR (CENTER OF LIFTGATE) REARVIEW CAMERA RECIRCULATION ACTUATOR RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT AIR TEMPERATURE ACTUATOR RIGHT I/P JUNCTION BLOCK (RIGHT END OF DASH) RUN/CRANK RELAY SERIAL DATA GATEWAY (SDG) MODULE (HYBRID) SPO ACCESSORY HEADREST DVD TAN WIRE TO TRANS IGN 1 FUSE 19 (DIAGRAM 8 OF 8) TRANSFER CASE SHIFT CONTROL MODULE (W/ AUTO UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) W/ COMFORT, DECOR LEVEL 3 CONVENIENCE PACKAGE W/ HEATED STEERING WHEEL W/ REAR A/C W/ REAR VIEW CAMERA W/ SPO REAR VISION CAMERA W/O HEATED STEERING WHEEL W/O SPO REAR VISION CAMERA WIPER/ WASHER SYSTEM YEL WIRE

Go to component: Trunk, tailgate, fuel door -> Liftgate release circuit -> L/GATE PCB RELAY
