Chevrolet Suburban XI (2007-2013) left side object sensor Wiring diagram

This page shows the only wiring diagram for the component.left side object sensor, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left side object sensor

Wiring diagram left side object sensor for Chevrolet Suburban XI (2007-2013)

Get access

2 3 4 5 B+ DATA DATA GROUND 5 6 4 2 GROUND GROUND DATA B+ BLK WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DRIVER DOOR LOCK/ WINDOW SWITCH DRIVER OUTSIDE REARVIEW MIRROR GMLAN HOT AT ALL TIMES I/P FUSE BLOCK (LEFT END OF DASH) LEFT SIDE OBJECT SENSOR OBS DET FUSE PASSENGER DOOR LOCK/WINDOW SWITCH PASSENGER OUTSIDE REARVIEW MIRROR PNK LED SIG WIRE PNK WIRE PNK/BLK WIRE POWER LIFTGATE MODULE (LEFT REAR OF CARGO AREA) RED WIRE RED/WHT WIRE RIGHT SIDE OBJECT SENSOR SIG RTN WHT WIRE

Go to component: Navigation -> Blind spot monitoring circuit -> LEFT SIDE OBJECT SENSOR
