Chevrolet Suburban XI (2007-2013) hot w/ park lamp relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ park lamp relay energized, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ park lamp relay energized
10 8 9 SERIAL DATA SERIAL DATA BUS +
ANTI-LOCK BRAKES PNK SYSTEM WIRE
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRAKE SIG
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
HOT W/ BCK/UP LAMP RELAY ENERGIZED
HOT W/ PARK LAMP RELAY ENERGIZED
HOT W/ RUN/CRNK RELAY ENERGIZED
LEFT I/P JUNCTION BLOCK (LEFT END OF DASH)
LT BLU/WHT WIRE
LT GRN WIRE
LT TURN SIG LAMP
MISC-IGN FUSE 43
ORG/ WIRE
PNK PNK PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/BLK WIRE
RT TURN SIG LAMP
SERIAL DATA BUS-
STOP LAMP SWITCH (TOP OF BRAKE PEDAL BRACKET)
STUD 1 FUSE 68
STUD 2 FUSE 63
TAN WIRE
TAN/BLK WIRE
TRAILER CONNECTOR (CENTER REAR OF VEHICLE)
TRAILER PROVISION (BLUNT CUT)
TRLR BCK/UP FUSE 10
TRLR PRK FUSE 25
TRLR STOP LT FUSE 3
TRLR STOP LT PCB RELAY
TRLR STOP RT FUSE 1
TRLR STOP RT PCB RELAY
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component: Exterior lights -> Trailer tow circuit -> HOT W/ PARK LAMP RELAY ENERGIZED
