Chevrolet Suburban XI (2007-2013) (bucket seat: approximately Wiring diagram
This page shows the only wiring diagram for the component.(bucket seat: approximately, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (bucket seat: approximately
AIR BAG
AIR BAG IND
BAG ON
BELT IND PASS SEAT
BLK WIRE
CHEVROLET/ GMC
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/BLK WIRE
DK GRN/WHT WIRE
DRIVER INFLATABLE RESTRAINT SEAT POSITION SENSOR (UNDER DRIVER'S SEAT)
DRIVER SEAT BELT PRETENSIONER
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE (DRIVER'S SEAT BELT BUCKLE)
GMLAN LO SPD
GRY WIRE
GRY/BLK WIRE
IND CTRL
IND CTRL BAG OFF PASS AIR
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INSTRUMENT PANEL CLUSTER
LEFT I/P JUNCTION BLOCK (LEFT END
LOGIC
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
OF DASH)
OFF IND
ON IND.
PASS AIR
PASSENGER SEAT BELT PRETENSIONER
PNK WIRE
PNK/BLK WIRE
PPL
SEAT BELT IND
SHORTING BAR
TAN/ORG WIRE
TAN/WHT WIRE
W/ NON BUCKET FRONT INDIVIDUAL SEAT
WHT/BLK WIRE
YEL WIRE
Go to component: Supplemental restraints -> Supplemental restraints circuit (2 of 3) -> (BUCKET SEAT: APPROXIMATELY
