Chevrolet Suburban XI (2007-2013) back sw ctrl wiring diagram
This page shows the only wiring diagram for the component.back sw ctrl, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
back sw ctrl wiring diagram (1 of 1)
BACK IND
BACK IND CTRL
BACK SW CTRL
BACK SWITCH
BACK, CUSHION IND CTRL
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOL IND
COOL SWITCH
CUSHION/BACK IND
CUSHION/BACK SWITCH
DIMMING CTRL
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER DOOR LOCK/WINDOW SWITCH
DRIVER HEATED, COOLED SEAT SWITCH (CHEVROLET, GMC)
GRY WIRE
HI TEMP IND CTRL
HIGH IND
LOW IND
LOW REF
LOW TEMP IND CTRL
LT BLU WIRE
LT GRN/BLK WIRE
MED IND
MED TEMP IND CTRL
ORG/ WIRE
PASSENGER DOOR LOCK/WINDOW SWITCH
PASSENGER HEATED, COOLED SEAT SWITCH (CHEVROLET, GMC)
PNK LOW REF WIRE
PNK WIRE
PPL
PPL BACK IND CTRL
SERIAL DATA
TAN WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Climate control seats circuit (2 of 2) -> BACK SW CTRL
