Chevrolet Suburban XI (2007-2013) assist left step side control object module sensor Wiring diagram
This page shows the only wiring diagram for the component.assist left step side control object module sensor, which is found in the car Chevrolet Suburban XI (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram assist left step side control object module sensor (1 of 1)
A/C COMPRESSOR CLUTCH
ASSIST LEFT STEP SIDE CONTROL OBJECT MODULE SENSOR
AUTOMATIC TRANSMISSION AUXILIARY FLUID PUMP CONTROL MODULE
AUTOMATIC TRANSMISSION CONTROL SOLENOID VALVE ASSEMBLY
AUXILIARY FUSE FAN BLOCK (HYBRID) (LEFT SIDE OF ENGINE COMPT) LO RELAY
BACKUP LAMP PCB RELAY
BATTERY
BLK WIRE
DIODES
ENGINE CONTROL MODULE (ECM)
EXCEPT HYBRID
EXCEPT HYBRID HYBRID
FAN CNTRL RELAY DIODE
FROM BREAKOUT TO FUSE UNDERHOOD FUSE BLOCK)
FRONT DRIVE AXLE ACTUATOR
FUEL PUMP RELAY
FUSE FUSE
IGNITION COIL 1
IGNITION COIL 6
IGNITION COIL 7
IGNITION COIL 8
IGNITION IGNITION COIL 4 COIL 2
IGNITION IGNITION COIL 5 COIL 3
LEFT ENGINE COOLING FAN
LEFT ENGINE COOLING FAN RESISTOR
LT BLU WIRE
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
MOBILE RADIO FUSE BLOCK
NCA WIRE
POWER SUPPLY
REAR DEFOG RELAY
REAR WASH PCB RELAY
RELAY RELAY
RIGHT SIDE OBJECT SENSOR
RUN/ CRNK RELAY
STRTR RELAY
TRANSFER CASE SHIFT CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
W/ ACTIVE 2 SPEED PUSH BUTTON CONTROL TRANSFER CASE
W/O SIDE POWER RUNNING BOARDS
WHT WIRE
WINDSHIELD WIPER MOTOR
WIPER 1 PCB RELAY
Go to component -> Ground distribution circuit (2 of 6) -> ASSIST LEFT STEP SIDE CONTROL OBJECT MODULE SENSOR
