Chevrolet Suburban X (2000-2006) sensor pwr battery ground sensor ref serial data Wiring diagram
This page shows the only wiring diagram for the component.sensor pwr battery ground sensor ref serial data, which is found in the car Chevrolet Suburban X (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensor pwr battery ground sensor ref serial data (1 of 1)
58 59 SERIAL DATA SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN)
BODY RELAY BLOCK (UNDER LEFT SIDE OF DASH)
DATA
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) PPL
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, START
INSTRUMENT PANEL CLUSTER
KEY
LT GRN WIRE
MAGNET LOCK CYLINDER
ORG/ WIRE
PASSLOCK SENSOR (INTERNAL TO STEERING COLUMN)
PNK IGN PWR WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT)
PPL
RED/WHT WIRE
SECURITY SENSOR
SENSOR PWR BATTERY GROUND SENSOR REF SERIAL DATA
SENSOR SIG SERIAL DATA GROUND
SPLICE
TAMPER SENSOR
TBC BATT FUSE
TBC IGN 1 FUSE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT)
YEL WIRE
Go to component: -> Passlock circuit -> SENSOR PWR BATTERY GROUND SENSOR REF SERIAL DATA
