Chevrolet Suburban X (2000-2006) req torque Wiring diagrams

This page contains all the electrical diagrams for the component. req torque, in which he is found in the car Chevrolet Suburban X (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram req torque (1 of 2)

Wiring diagram req torque for Chevrolet Suburban X (2000-2006)

Get access

ABS FUSE ABS/TCS CLASS 2 SERIAL DATA YAW RATE SENSOR LO REF ANTI-LOCK IND BLK WIRE BLK/WHT WIRE BRAKE FLUID LEVEL SWITCH (2500 SERIES) (ON LEFT SIDE OF BRAKE FLUID RESERVOIR) BRAKE FUSE BRAKE IN BRAKE IND BRAKE PRESSURE DIFFERENTIAL SWITCH (1500 SERIES) (BELOW MASTER CYLINDER) BRN WIRE BRN/WHT WIRE DEL TORQUE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (ON LEFT REAR FRAME RAIL) EXCEPT SEO GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) BRAKE FUSE HOT IN RUN OR START IGN E FUSE IGNITION 3 VOLT IGNITION 3 VOLTAGE LEFT FRONT SENSOR (-) RIGHT FRONT SENSOR (+) DELIVERED TORQUE ILLUM LAMP INSTRUMENT CLUSTER LATERAL ACCELEROMETER SIG LEFT FRONT WHEEL SPEED SENSOR LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LEFT REAR WHEEL SPEED SENSOR LOGIC LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/BLK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (ON LEFT FRONT OF ENG COMPT) POWERTRAIN OR ENGINE CONTROL MODULE (PCM OR ECM) (AT LEFT FRONT OF ENG COMPT) PPL PPL 1500: BRAKE PRESS SENS SIG 2500: BRAKE FLUID LEVEL SW PPL DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, BELOW STEERING COLUMN) PPL/WHT WIRE PRECHARGE MOTOR LO BATTERY (+) GND PRECHARGE MOTOR HI PRECHARGE PUMP RED WIRE REQ TORQUE REQUEST TORQUE SIGNAL DELIVERED TORQUE SIGNAL RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR SEO SEO IGN FUSE STEERING WHEEL POS MARKER PULSE SIG STEERING WHEEL POS SIG B STOPLAMP SWITCH (ON TOP OF BRAKE PEDAL BRACKET) TAN WIRE TAN/BLK WIRE TCC BRAKE SW TRACTION CONTROL IND TRACTION CONTROL SWITCH (IF EQUIPPED) TRANSFER CASE SHIFT CONTROL MODULE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENG COMPT, NEAR BATTERY) ABS FUSE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) VEHICLE SPEED SENSOR (VSS) (RIGHT REAR OF TRANSMISSION) VSES MOTOR VSES/ECAS FUSE VSS HIGH VSS LOW VSS OUT VSS OUTPUT WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component: Anti-lock brakes -> Anti-lock brakes circuit, without vehicle speed enhancement stability -> REQ TORQUE
