Chevrolet Suburban X (2000-2006) left front park/ turn signal lamp Wiring diagram

BACK-UP LAMPS CIRCUIT BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK LT FRT PARK FUSE GRN WIRE GRY WIRE GRY/BLK WIRE HAZARD SWITCH HEAD PARK ANL/ DRL AUTO HEADLAMP SWITCH HOT AT ALL TIMES HOT IN RUN AND START I/P RELAY BLOCK IGN E FUSE LEFT FRONT MARKER LAMP LEFT FRONT PARK/ TURN SIGNAL LAMP LEFT RIGHT LT BLU WIRE LT GRN WIRE PARK LAMP RELAY PNK WIRE PRK LMP ON REAR BODY MARKER LAMP RED WIRE RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/ TURN SIGNAL LAMP SERIAL DATA PRK LMP RLY SPLICE PACK STUD 1 FUSE STUD 2 FUSE TAN WIRE TO TRL PARK FUSE TRAILER CONNECTOR TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDER- HOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
