Chevrolet Suburban X (2000-2006) electronic brake control module Wiring diagrams

This page contains all the electrical diagrams for the component. electronic brake control module, in which he is found in the car Chevrolet Suburban X (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram electronic brake control module (1 of 2)

Wiring diagram electronic brake control module for Chevrolet Suburban X (2000-2006)

Get access

5.3L FLEX FUEL A/C COMPRESSOR CLUTCH A/C LOW PRESSURE SWITCH ACTIVE TRANSFER CASE AIR TEMPERATURE ACTUATOR (AUXILIARY) AIR TEMPERATURE ACTUATOR (LEFT) AUTO A/C AUTOMATIC LEVEL CONTROL RELAY AUTOMATIC TRANSMISSION AUXILIARY POWER CENTER (FUSE/ RELAY BLOCK) RELAY B BATTERY (LEFT) BATTERY (RIGHT) BLK WIRE BLUNT CUT) BODY CONTROL MODULE BRAKE FLUID LEVEL SWITCH BRAKE FUSE BRAKE PRESSURE DIFFERENTIAL SWITCH BRN WIRE CADILLAC EXCEPT CADILLAC COOLANT LEVEL SWITCH CRANK FUSE CRUISE CONTROL ON/OFF SWITCH DAYTIME RUNNING HORN LAMP (DRL) (RIGHT) (RIGHT) DAYTIME RUNNING LAMP (DRL) (LEFT) ELECTRONIC BRAKE CONTROL MODULE ELECTRONIC SUSPENSION CONTROL MODULE ESCALADE EXT EXCEPT ESCALADE EXT F/PMP RELAY FOG LAMP (LEFT) FOG LOW BEAM LAMP HEADLAMP (RIGHT) (RIGHT) FROM IGN A FUSE (DIAGRAM 1 OF 6) FRONT AXLE ACTUATOR FUEL COMPOSITION SENSOR FUEL PUMP, SENDER ASSEMBLY (PRIMARY) FUEL PUMP, SENDER ASSEMBLY (SECONDARY) FUSE FUSE FUSE HEADLAMP BALLAST (LEFT) HEADLAMP HIGH BEAM (LEFT) HIGH BEAM HEADLAMP (LEFT) HIGH BEAM HEADLAMP (RIGHT) HIGH BEAM HEADLAMP (RIGHT) HEADLAMP BALLAST (RIGHT) HORN (LEFT) HTR/AC FUSE CRUISE FUSE HVAC 1 FUSE HVAC CONTROL MODULE HVAC CONTROL PROCESSOR (AUXILIARY) HVAC CONTROL ASSEMBLY (REAR AUXILIARY) IGN 0 FUSE IGN 1 RELAY IGN 3 FUSE IGNITION SWITCH INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LOCK OFF LOW BEAM HEADLAMP (LEFT) MAN A/C MANUAL A/C AUTO A/C MODE ACTUATOR (AUXILIARY) AUTOMATIC LEVEL CONTROL RELAY MODE ACTUATOR RECIRCULATION ACTUATOR AIR TEMPERATURE ACTUATOR (RIGHT) NCA WIRE ORG/ WIRE PARK/TURN SIGNAL LAMP (LEFT FRONT) PARK/TURN SIGNAL LAMP (RIGHT FRONT) PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE PPL PNK WIRE REAR WHEEL STEERING CONTROL MODULE REAR WINDOW WASHER FLUID PUMP RED WIRE RELAY A RIGHT I/P FUSE BLOCK (LOWER RIGHT SIDE OF DASH) RUN WIRE STEERING WHEEL SPEED/ POSITION SENSOR STOPLAMP SWITCH TRACTION CONTROL SWITCH TBC IGN 0 FUSE THEFT DETERRENT CONTROL MODULE THROTTLE ACTUATOR CONTROL MODULE TRANSFER CASE SHIFT CONTROL MODULE TRANSFER CASE SHIFT CONTROL SWITCH TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) UPFITTER OPTION W/ DUAL HORNS W/ HID W/ VSES W/DUAL BATTERY W/HID W/O HID W/O ULT W/ ULT W/O VSES W/VSES WASHER FLUID LEVEL SWITCH WHT WIRE WINDSHIELD WASHER FLUID PUMP YEL WIRE

Go to component: Ground distribution -> Ground distribution circuit (1 of 5) -> ELECTRONIC BRAKE CONTROL MODULE
