Chevrolet Suburban X (2000-2006) b/u lp fuse Wiring diagrams

This page contains all the electrical diagrams for the component. b/u lp fuse, in which he is found in the car Chevrolet Suburban X (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram b/u lp fuse (1 of 3)

Wiring diagram b/u lp fuse for Chevrolet Suburban X (2000-2006)

Get access

A/T SHIFT LOCK CONTROL SOLENOID (ON STEERING COLUMN) AUTOMATIC LEVEL RELAY AUXILIARY POWER CENTER FUSE/ RELAY BLOCK B/U LMP VLT B/U LMPS SIG B/U LP FUSE BLK WIRE BODY CONTROL MODULE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH, BELOW STEERING COLUMN) BRN WIRE BTSI FUSE CLIMATE CONTROL SEAT MODULE (DRIVER) CLIMATE CONTROL SEAT MODULE (FRONT PASSENGER) CLIMATE CONTROL SEAT MODULE (LEFT REAR) CLIMATE CONTROL SEAT MODULE (RIGHT REAR) CONVERTER) DEFOG RELAY DK BLU WIRE DK GRN WIRE DRIVER, PASSENGER SWITCH ELECTRONIC SUSPENSION CONTROL MODULE EXC 8.L W/O CALIFORNIA LEV FROM IGN 3 FUSE (DIAGRAM 5 OF 6) FROM IGN B FUSE (DIAGRAM 1 OF 6) FUSE GRN WIRE GRY WIRE HEATED OXYGEN SENSOR BANK 1 SENSOR 1 HEATED OXYGEN SENSOR BANK 2 SENSOR 1 HEATED OXYGEN SENSOR BANK 1 SENSOR 2 HEATED OXYGEN SENSOR BANK 2 SENSOR 2 HEATED/ COOLED CUP HOLDER RELAY HOT IN RUN OR START I/P RELAY BLOCK I/P RELAY BLOCK (UNDER LEFT SIDE OF DASH, NEAR KICK PANEL) IGN E FUSE A/C COMP RELAY IGNITION SWITCH INFLATABLE RESTRAINT PASSENGER PRESENCE MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE INSIDE REARVIEW MIRROR INSTRUMENT PANEL CLUSTER REAR OBJECT SENSOR CONTROL MODULE INSTRUMENT PANEL CLUSTER TURN SIGNAL/ MULTI- FUNCTION SWITCH LEFT BACK-UP LAMP LEFT I/P FUSE BLOCK (BEHIND LOWER LEFT SIDE OF DASH) LEFT REAR SWITCH LOCK LOCK OFF LOGIC LT BLU WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION) PARK/NEUTRAL POSITION (PNP) SWITCH (LEFT SIDE OF TRANSMISSION) PARK/NEUTRAL POSITION SWITCH PARKING ASSIST CIRCUIT PNK PNK PNK PNK PNK PNK WIRE PNK PNK PNK WIRE PNK PNK WIRE PNK WIRE REAR LAMPS JUNCTION BLOCK REAR WIPER/ WASHER SWITCH RED WIRE RELAY A RELAY B RIGHT BACK-UP LAMP RIGHT REAR SWITCH RR WPR FUSE RUN WIRE SEO ACCY FUSE SEO IGN FUSE SIR FUSE STOPLAMP SWITCH TAN WIRE TBC ACCY FUSE TBC IGN 1 FUSE TO IGN 1 RELAY (DIAGRAM 3 OF 6) TRAILER CONNECTOR TRLR B/U FUSE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT, NEAR BATTERY) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY) WHT WIRE WINDSHIELD WIPER MOTOR MODULE WS WPR FUSE YEL WIRE

Go to component: Exterior lights -> Back-up lamps circuit -> B/U LP FUSE
