Chevrolet Suburban X (2000-2006) battery rap relay Wiring diagram

This page shows the only wiring diagram for the component.battery rap relay, which is found in the car Chevrolet Suburban X (2000-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram battery rap relay (1 of 1)

Wiring diagram battery rap relay for Chevrolet Suburban X (2000-2006)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 CLOSE OPEN BATTERY RAP RELAY BLK WIRE BRN WIRE DK BLU WIRE DK GRN WIRE GROUND HOT AT ALL TIMES HOT W/RAP RELAY ENERGIZED MTR OUT 1 MTR OUT 2 SUN ROOF MODULE (ABOVE FRONT OF HEAD LINER) ORG/ WIRE RED WIRE RIGHT I/P FUSE BLOCK (LOWER RIGHT SIDE OF DASH) SUN ROOF FUSE SUN ROOF RELAY (AT LOWER SIDE OF RIGHT "A" PILLAR) SUNROOF MOTOR (NEAR RIGHT "A" PILLAR) SUNROOF SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEAR BATTERY)

Go to component: -> Moonroof circuit -> BATTERY RAP RELAY
