Chevrolet Suburban X (2000-2006) bare drain wire r spk out- l spk out- b+ Wiring diagrams

This page contains all the electrical diagrams for the component. bare drain wire r spk out- l spk out- b+, in which he is found in the car Chevrolet Suburban X (2000-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram bare drain wire r spk out- l spk out- b+ (1 of 2)

Wiring diagram bare drain wire r spk out- l spk out- b+ for Chevrolet Suburban X (2000-2006)

Get access

5 6 7 8 9 10 11 12 13 14 15 PPL AUDIO AMPLIFIER BARE BARE DRAIN WIRE R SPK OUT- L SPK OUT- B+ BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE GROUND L SPK OUT+ R SPK OUT+ GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P RELAY BLOCK (BELOW LOWER LEFT SIDE OF DASH) LEFT "D" PILLAR (EXCEPT ESCALADE EXT) LEFT FRONT TWEETER SPEAKER LEFT FRONT DOOR SPEAKER LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) LEFT REAR DOOR SPEAKER LEFT SUBWOOFER LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK BARE WIRE PNK WIRE RADIO FUSE RIGHT "D" PILLAR (EXCEPT ESCALADE EXT) RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH) RIGHT REAR DOOR SPEAKER RIGHT SUBWOOFER SUBWOOFER SPEAKER TAN WIRE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT) YEL WIRE

Go to component: -> Mid-line radio circuit, without rear seat audio (2 of 3) -> BARE DRAIN WIRE R SPK OUT- L SPK OUT- B+

Wiring diagram bare drain wire r spk out- l spk out- b+ (2 of 2)

Wiring diagram bare drain wire r spk out- l spk out- b+ for Chevrolet Suburban X (2000-2006)

Get access

4 5 BARE AUDIO AMPLIFIER BARE BARE 6 7 8 9 10 11 12 13 14 15 16 17 BARE DRAIN WIRE R SPK OUT- L SPK OUT- B+ BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE GROUND L SPK OUT+ R SPK OUT+ GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P RELAY BLOCK (BELOW LOWER LEFT SIDE OF DASH) LEFT "D" PILLAR (EXCEPT ESCALADE EXT) LEFT FRONT TWEETER SPEAKER LEFT FRONT DOOR SPEAKER LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH) LEFT REAR DOOR SPEAKER LEFT SUBWOOFER LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK BARE WIRE PNK WIRE PPL RADIO FUSE RIGHT "D" PILLAR (EXCEPT ESCALADE EXT) RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER SPEAKER RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH) RIGHT REAR DOOR SPEAKER RIGHT SUBWOOFER SUBWOOFER SPEAKER TAN WIRE UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT) YEL WIRE

Go to component: -> Mid-line radio circuit, with rear seat audio (2 of 3) -> BARE DRAIN WIRE R SPK OUT- L SPK OUT- B+
