Electrochromic mirror circuit for Chevrolet Suburban C2500 (1992-1999)
Electrochromic mirror circuit
BLK WIRE
BRN WIRE
GAUGES FUSE 4
GRY WIRE
HEADLAMP AMBIENT SENSOR SENSOR (MIRROR (WINDSHIELD SIDE) SIDE)
HOT IN RUN OR START
I/P FUSE BLOCK (UNDER LEFT SIDE OF DASH)
INSIDE AUTOMATIC DAY-NIGHT MIRROR
LEFT OUTSIDE AUTOMATIC DAY-NIGHT MIRROR
LT GRN WIRE
MANUAL TRANSMISSION AUTOMATIC TRANSMISSION
MIRROR INPUT
MIRRORS SWITCH
NCA WIRE
OFF C/M
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RIGHT OUTSIDE AUTOMATIC DAY-NIGHT MIRROR
T/M
TEMPERATURE SENSOR (IN ENGINE COMPARTMENT, NEAR LOWER RADIATOR SUPPORT)
TURN B/U FUSE 16
