Chevrolet Suburban C2500 (1992-1999) shift sole- noid 1-2 shift solenoid 2-3 Wiring diagram

3-2 SHIFT SOLENOID ALL EXCEPT 5.7L W/ BLK WIRE BLK/WHT WIRE BRN OR TAN/BLK WIRE BRN WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF I/P) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM-B MINI FUSE ELECTRONIC 4-SPEED AUTOMATIC OVERDRIVE TRANSMISSION FUEL PUMP AND SENDER FUEL PUMP OIL PRESSURE SWITCH (TOP REAR OF ENGINE NEAR DISTRIBUTOR) FUEL PUMP PRIME CONN- ECTOR FUEL PUMP RELAY (UNDERHOOD FUSE/RELAY CENTER) GRY WIRE HEATED OXYGEN SENSOR (IN EXHAUST Y-PIPE) HOT AT ALL TIMES HOT IN RUN OR START I/P FUSE BLOCK (BEHIND LEFT SIDE OF I/P) INSTRUMENT CLUSTER LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE OIL PRESS IN ONLY ORG/ WIRE PNK WIRE PPL PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SHIFT SOLE- NOID 1-2 SHIFT SOLENOID 2-3 SOLENOID TACH IN TAN WIRE TAN/BLK BRN OR WIRE TAN/BLK WIRE TORQUE CONVERTER CLUTCH TRANS FUSE 20 TRANS- MISSION TEMP SENSOR UNDERHOOD FUSE/RELAY CENTER (LEFT REAR OF ENGINE COMPT) VEHICLE SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (UNDER RIGHT END OF I/P) VSS IN WHT WIRE WHT/BLK WIRE YEL/BLK WIRE
