Chevrolet Suburban C1500 (1992-1999) 3 22 speed sensor output Wiring diagram

3 22 SPEED SENSOR OUTPUT BLK WIRE BLK/WHT WIRE BLU WIRE BRAKE FUSE 18 BRN WIRE BRN/WHT WIRE CLUTCH PEDAL POSITION SWITCH (TOP OF CLUTCH PEDAL) CRUISE CONTROL MODULE (LEFT REAR OF ENGINE COMPARTMENT) CRUISE CONTROL SWITCH CRUISE ENGAGE INPUT CRUISE FUSE 6 CRUISE ON INPUT SET/COAST SIG RESUME/ACCEL SIG DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL SYSTEM EXTERIOR LIGHT SYSTEM GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN I/P FUSE BLOCK (LEFT SIDE OF DASH, LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE M/T A/T M/T A/T (I/P HARN, LEFT REAR OF ENGINE COMPT) OFF (OR ON (OR PNK) WIRE ORG/ WIRE PPL PPL SHIFT INTER- LOCK SYSTEM PPL/WHT WIRE STOP/HAZ FUSE 1 STOPLAMP SWITCH (TOP OF BRAKE PEDAL) VCM SIGNAL SPEED SENSOR INPUT VEHICLE CONTROL MODULE (VCM) (LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (LEFT SIDE OF TRANSMISSION) VSS HIGH VSS LOW WHT WIRE
