Supplemental restraints circuit for Chevrolet SSR I (2003-2006)

AIR BAG AIR BAG FUSE 14 BLK WIRE BLK/WHT WIRE BRN WIRE DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DRIVER SEAT BELT SWITCH (IN DRIVER SEAT BELT BUCKLE) GROUND GRY WIRE HOT IN RUN OR START I/P MODULE DISABLE SWITCH SIGNAL I/P MODULE SUPPRESSION INDICATOR CONTROL IGNITION 1 VOLTAGE INFLATABLE RESTRAINT I/P MODULE INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR INFLATABLE RESTRAINT SENSING/DIAGNOSTIC MODULE (BELOW LOWER CONSOLE) INFLATABLE RESTRAINT STEERING WHEEL MODULE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER IPC CLASS 2 SERIAL DATA KEY SWITCH LEFT INFLATABLE RESTRAINT SEAT POSITION SENSOR (UNDER LEFT SEAT BOTTOM ON TRACK) LEFT INFLATABLE RESTRAINT SIDE IMPACT MODULE (INSIDE DRIVER SEAT BACK) LEFT INFLATABLE RESTRAINT SIDE IMPACT SENSOR (INSIDE DRIVER DOOR) LEFT SEAT BELT PRETENSIONER LOGIC LT BLU WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/BLK WIRE PASSENGER AIR BAG OFF PNK WIRE PPL RIGHT INFLATABLE RESTRAINT SEAT POSITION SENSOR (UNDER PASSENGER SEAT) RIGHT INFLATABLE RESTRAINT SIDE IMPACT MODULE (INSIDE PASSENGER SEAT BACK) RIGHT INFLATABLE RESTRAINT SIDE IMPACT SENSOR (INSIDE PASSENGER DOOR) RIGHT SEAT BELT PRETENSIONER SHORTING BAR SPLICE STAGE 1 STAGE 2 TAN WIRE TAN/BLK WIRE TWISTED PAIR WIRES UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
