Car Wiring Diagrams for Heated seats circuit for Chevrolet SSR I (2003-2006)

5 VOLT REF BATT + BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK BLU WIRE DR SEAT MOD FUSE 6 DRIVER BACK HEATED SEAT ELEMENT DRIVER CUSHION HEATED SEAT ELEMENT DRIVER HEATED SEAT SWITCH DRIVER MEMORY SEAT MODULE (BELOW LEFT FRONT SEAT) GND BAT (+) GRN WIRE HOT AT ALL TIMES LOGIC LOW HIGH/ LOW SIG OHMS HIGH LOW REF LT GRN WIRE NCA WIRE OHMS OHMS HIGH ORG/ WIRE PASSENGER BACK HEATED SEAT ELEMENT PASSENGER CUSHION HEATED SEAT ELEMENT PASSENGER HEATED SEAT SWITCH PASSENGER SEAT BELT SWITCH PNK WIRE REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT) RED WIRE RED/WHT WIRE RIGHT SEAT BELT SWITCH SEATS CIRCUIT BREAKER 8 WHT WIRE YEL WIRE
