Instrument illumination circuit for Chevrolet SSR I (2003-2006)

AUXILIARY GAUGE CENTER BATTERY BATTERY BATTERY BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH ASSEMBLY CLASS 2 DATA GROUND COMPUTER DATA LINES SYSTEM DIM CONTROL CLASS 2 DATA GROUND DIMMING CTRL DIMMING CTRL DIM LOW REF FUSE 4 FUSE 40 FUSE 7 GRY WIRE GRY/BLK WIRE HEADLAMP SWITCH HOT AT ALL TIMES HVAC CONTROL MODULE I/P DIMMER SWITCH ILLUM INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT PANEL CLUSTER (IPC) (8 BULBS) LEFT STEERING WHEEL CONTROLS LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE RADIO REAR COMPARTMENT LID RELEASE SWITCH (INTERIOR) REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT) RIGHT STEERING WHEEL CONTROLS SPLICE PACK STEERING COLUMN FUSE HOLDER STEERING WHEEL CONTROLS ASSEMBLY WHT WIRE YEL WIRE
