Back-up lamps circuit for Chevrolet SSR I (2003-2006)
Back-up lamps circuit
34 72 TR SW P TR SW B
BATTERY B/U LMP VOLT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (REAR CENTER OF PASSENGER COMPT)
DK GRN WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
LEFT BACKUP LAMP
LT GRN WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH (LOWER LEFT SIDE OF TRANSMISSION)
POWERTRAIN CONTROL MODULE (LEFT FRONT SIDE OF ENGINE COMPT)
REAR FUSE BLOCK (BELOW LEFT REAR SEAT) FUSE 7
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RIGHT BACKUP LAMP
SER DATA
SERIAL DATA
TR SW A
TR SW C
WHT WIRE
YEL WIRE
