Chevrolet SSR I (2003-2006) low ref tp sens 2 uart data uart data cruise on ground tac ctrl ppl Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 TP SENS 1 20 21 49 VSS LOW SIG VSS HIGH SIG SPEED SIG 58 59 33 14 15 SERIAL DATA SERIAL DATA TCC BRK SW UART DATA UART DATA ACCELERATOR PEDAL POSITION SENSOR (ABOVE ACCELERATOR PEDAL) APP SENS 1 BLK WIRE BLK/WHT WIRE BRN WIRE CLOSE COMPUTER DATA LINES SYSTEM CRUISE INDICATOR DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF INNER FRAME RAIL) GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN, START HVAC I FUSE 39 IGN E FUSE 9 IGNITION INSTRUMENT PANEL CLUSTER (IPC) LOW REF S/C INPUT R/A INPUT STP LP IN IGN 1 VOLT TAC CNTRL LOW REF TP SENS 2 UART DATA UART DATA CRUISE ON GROUND TAC CTRL PPL LT BLU WIRE LT GRN/BLK WIRE ON/OFF SWITCH ORG/ WIRE ORG/BLK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (LEFT FRONT SIDE OF ENGINE COMPT) PPL PPL REF LOW APP SENS 2 PPL/WHT WIRE REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPARTMENT) REF LOW RES/ACCEL SWITCH SERIAL DATA SERIAL DATA TCC BRK SW SPEED SIG PPL SET/COAST SWITCH ST/LP FUSE 33 STOP FUSE 34 STOP LAMP SWITCH (TOP OF BRAKE PEDAL BRACKET) TAN WIRE THROTTLE ACTUATOR CONTROL MODULE (LEFT REAR OF ENGINE COMPT) TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) ETC FUSE 20 VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSMISSION) WHT WIRE YEL WIRE YEL/BLK WIRE
