Chevrolet SSR I (2003-2006) low high/ low sig ohms high Wiring diagram
This page shows the only wiring diagram for the component.low high/ low sig ohms high, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low high/ low sig ohms high (1 of 1)
5 VOLT REF
BATT +
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DR SEAT MOD FUSE 6
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER HEATED SEAT SWITCH
DRIVER MEMORY SEAT MODULE (BELOW LEFT FRONT SEAT)
GND BAT (+)
GRN WIRE
HOT AT ALL TIMES
LOGIC
LOW HIGH/ LOW SIG OHMS HIGH
LOW REF
LT GRN WIRE
NCA WIRE
OHMS
OHMS HIGH
ORG/ WIRE
PASSENGER BACK HEATED SEAT ELEMENT
PASSENGER CUSHION HEATED SEAT ELEMENT
PASSENGER HEATED SEAT SWITCH
PASSENGER SEAT BELT SWITCH
PNK WIRE
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RED WIRE
RED/WHT WIRE
RIGHT SEAT BELT SWITCH
SEATS CIRCUIT BREAKER 8
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> LOW HIGH/ LOW SIG OHMS HIGH
