Chevrolet SSR I (2003-2006) interior rear compartment lid release switch wiring diagram

14 13 RR COMPT LID AJAR SW SIG RR COMPT LID REL SW SIG 5 7 BATTERY BATTERY BED COVER RELEASE FUSE 31 BEDCOVER RELEASE RELAY 38 BLK WIRE BRN WIRE EXTERIOR REAR COMPARTMENT LID RELEASE SWITCH/ACTUATOR GRN WIRE HOT AT ALL TIMES INTERIOR REAR COMPARTMENT LID RELEASE SWITCH LT GRN WIRE NCA WIRE ORG/ WIRE RDM 2 FUSE 28 REAR COMPARTMENT AJAR SWITCH REAR COMPARTMENT PRESENT SWITCH REAR FUSE BLOCK REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT) RED WIRE RED/BLK WIRE ROOF/DOOR CB 1 ROOF/DOOR MODULE (REAR CENTER OF PASSENGER COMPT) RR COMPT LID REL RLY CTRL RR COMPT PRESENT SW SIG SPLICE PACK TAN WIRE UNDER- HOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE
