Chevrolet SSR I (2003-2006) ignition 3 lf whl spd sens ref rf whl spd sens sig delivered torque sig Wiring diagram
This page shows the only wiring diagram for the component.ignition 3 lf whl spd sens ref rf whl spd sens sig delivered torque sig, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition 3 lf whl spd sens ref rf whl spd sens sig delivered torque sig (1 of 1)
ABS FUSE 48
ABS INDICATOR
ABS PUMP
BLK WIRE
BODY CONTROL MODULE (BCM) (REAR CENTER OF PASS COMPT)
BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER FLUID RESERVOIR)
BRAKE FLUID LVL SIG
BRAKE FUSE 51
BRAKE INDICATOR
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE SWITCH ASSEMBLY
CRUISE CONTROL SYSTEM PPL PPL
DELIVERED TORQUE SIGNAL
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
HVAC 1 FUSE 39
IGN E FUSE 9
IGNITION 3 LF WHL SPD SENS REF RF WHL SPD SENS SIG DELIVERED TORQUE SIG
INSTRUMENT PANEL CLUSTER
LEFT FRONT WHEEL SPEED SENSOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT FRONT SIDE OF ENG COMPT)
PPL
REAR FUSE BLOCK (REAR CENTER OF PASS COMPT)
RED WIRE
REQUESTED TORQUE SIGNAL
RIGHT FRONT WHEEL SPEED SENSOR
SERIAL DATA
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TAN WIRE
TAN/BLK WIRE
TRACTION DISABLED INDICATOR
TRACTION ON/OFF SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) IPC/DIC FUSE 24
VEHICLE SPEED SIGNAL
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit -> IGNITION 3 LF WHL SPD SENS REF RF WHL SPD SENS SIG DELIVERED TORQUE SIG
