Chevrolet SSR I (2003-2006) hdm relay 41 Wiring diagrams
This page contains all the electrical diagrams for the component. hdm relay 41, in which he is found in the car Chevrolet SSR I (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hdm relay 41 (1 of 2)
A/C COMPRESSOR CLUTCH
BLK WIRE
BRAKE FLUID LEVEL SWITCH
F/PMP RELAY 35
FOLDING TOP MOTOR LEFT RELAY
FOLDING TOP MOTOR RIGHT RELAY
FOLDING TOP OUTER LATCH POSITION SWITCH
FOLDING TOP OUTER LATCH STRIKER POSITION SWITCH
FOLDING TOP PUMP/ MOTOR ASSEMBLY
HDM RELAY 41
IGN 1 RELAY 42
INSIDE REARVIEW MIRROR
INTAKE AIR TEMPERATURE (IAT)/MASS AIR FLOW (MAF) SENSOR
LEFT FRONT FOG LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT VANITY MIRROR LAMP
LOCK RELAY 18
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER DOOR LATCH ASSEMBLY PASSENGER WINDOW MOTOR
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT BELT SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RIGHT VANITY MIRROR LAMP
ROOF/ DOOR MODULE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNLOCK RELAY 24
Go to component -> Ground distribution circuit (2 of 3) -> HDM RELAY 41
Wiring diagram hdm relay 41 (2 of 2)
AMBIENT LIGHT SENSOR (TOP CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (NEAR REAR RELAY BLOCK)
CLASS 2 SER DATA
COILS FUSE 4
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRL DIODE
DRL FUSE 13
FLASH TO PASS HI BEAM
FOG LAMP IND
FOG LAMP SWITCH
FOG LMP RLY HI BM RLY CTRL DRL RLY CTRL LOW BM RLY CTRL CLSS 2 SER DATA
FOG LMPS ENABLE HDLMP DIM SW
FOG LP FUSE 11
FOG LP RELAY 36
FTP SIG
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HDLMP ON SIG
HDLP HI RELAY 37
HDM RELAY 41
HEAD
HEADLAMP DIMMER SWITCH
HEADLAMP SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
IGN IPC CLASS 2 SER DATA
INSTRUMENT PANEL CLUSTER
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HIGH BEAM HEAD- LAMP
LEFT LOW BEAM HEAD- LAMP
LOW BEAM
LOW REF
LT DRL RELAY
LT GRN WIRE
LT GRN/BLK WIRE
LT HI HDLP FUSE 7
LT LOW HDLP FUSE 11
OFF AUTO
ORG/ WIRE
PARK
PNK WIRE
PNK/WHT WIRE
PPL
PPL PPL
PRK LMPS ON SIG
REAR FUSE BLOCK
REAR RELAY BLOCK (REAR CENTER OF PASSENGER COMPT)
RIGHT HIGH BEAM HEAD- LAMP
RIGHT LOW BEAM HEAD- LAMP
RT DRL RELAY
RT HI HDLP FUSE 8
RT LOW HDLP FUSE 12
SEN SIG
TAN WIRE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit -> HDM RELAY 41
