Chevrolet SSR I (2003-2006) f/pmp relay 35 Wiring diagrams
This page contains all the electrical diagrams for the component. f/pmp relay 35, in which he is found in the car Chevrolet SSR I (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram f/pmp relay 35 (1 of 3)
A/C COMPRESSOR CLUTCH
BLK WIRE
BRAKE FLUID LEVEL SWITCH
F/PMP RELAY 35
FOLDING TOP MOTOR LEFT RELAY
FOLDING TOP MOTOR RIGHT RELAY
FOLDING TOP OUTER LATCH POSITION SWITCH
FOLDING TOP OUTER LATCH STRIKER POSITION SWITCH
FOLDING TOP PUMP/ MOTOR ASSEMBLY
HDM RELAY 41
IGN 1 RELAY 42
INSIDE REARVIEW MIRROR
INTAKE AIR TEMPERATURE (IAT)/MASS AIR FLOW (MAF) SENSOR
LEFT FRONT FOG LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT VANITY MIRROR LAMP
LOCK RELAY 18
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER DOOR LATCH ASSEMBLY PASSENGER WINDOW MOTOR
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT BELT SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RIGHT VANITY MIRROR LAMP
ROOF/ DOOR MODULE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNLOCK RELAY 24
Go to component -> Ground distribution circuit (2 of 3) -> F/PMP RELAY 35
Wiring diagram f/pmp relay 35 (2 of 3)
A/C FUSE 1
A/C RELAY 34
ABS FUSE 48
BATTERY
BED COVER FUSE 31
BED COVER RELEASE RELAY 38
BLK WIRE
BLOWER MOTOR
BLWR FUSE 45
CANISTER FUSE 3
CIGAR LIGHTER
COILS FUSE 4
COOLING FAN 1 RELAY
COOLING FAN 2 RELAY
DATA LINK CONNECTOR (DLC)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENG CLN FAN FUSE 44
ETC FUSE 20
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
F/PMP RELAY 35
FOG LP FUSE 21
FOG LP RELAY 36
FROM IGN E FUSE (DIAGRAM 4 OF 4)
FROM LTR FUSE 28 (DIAGRAM 1 OF 4)
FUEL INJECTOR 2 FUEL INJECTOR 4
FUEL INJECTOR 3 FUEL INJECTOR 1
FUEL INJECTOR 6 FUEL INJECTOR 8
FUEL INJECTOR 7 FUEL INJECTOR 5 IGNITION COIL 1 IGNITION COIL 3
FUSIBLE LINK (8 GA-
GENERATOR
HEADLAMP DRIVER MODULE (HDM) RELAY 41 HDLP- HI RELAY 37
HORN FUSE 22
HORN RELAY 39 W/S WASH RELAY 40
IGN 1 RELAY
IGNITION COIL 2 IGNITION COIL 4 IGNITION COIL 6
IGNITION COIL 5
IGNITION COIL 7
IGNITION COIL 8
INJ A FUSE 23
INJ B FUSE 42
INSTRUMENT PANEL CLUSTER (IPC)
IPC/DIC FUSE 10
LTR FUSE 28
ORG/ WIRE
PCM B FUSE 29
PNK PNK PNK PNK WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
SPLICE PACK
STARTER
TBC 1 FUSE 15 FLASH FUSE 32
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TO I/P BATT FUSE 49 (DIAGRAM 2 OF 4)
TO IGN 1 RELAY (DIAGRAM 1 OF 4)
TURN/ SIGNAL HAZARD FLASHER MODULE BODY CONTROL MODULE (BCM)
UNDERHOOD JUNCTION BLOCK
W/S WASH FUSE 27
Go to component -> Power distribution circuit (1 of 4) -> F/PMP RELAY 35
Wiring diagram f/pmp relay 35 (3 of 3)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CAMSHAFT POSITION SENSOR (TOP CENTER REAR OF ENGINE)
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
F/PMP RELAY 35
FUEL PUMP, SENDER ASSEMBLY (INSIDE FUEL TANK)
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) (LEFT EXHAUST PIPE, AHEAD OF CONVERTER)
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) (LEFT EXHAUST PIPE, BEHIND CONVERTER)
HEATED OXYGEN SENSOR (BANK 2 SENSOR 1) (RIGHT EXHAUST PIPE, AHEAD OF CONVERTER)
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) (RIGHT EXHAUST PIPE, BEHIND CONVERTER)
HOT AT ALL TIMES
KNOCK SENSOR 1 (TOP FRONT CENTER OF ENGINE)
KNOCK SENSOR 2 (TOP REAR CENTER OF ENGINE)
LT BLU WIRE
NCA WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION)
PCM B FUSE 29
PNK 1 2 3 4 5 WIRE
PNK 4 5 WIRE
PNK PNK 26 27 WIRE
PNK PNK 6 7 8 9 10 WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL PNK PNK WIRE
PPL PPL
PPL/WHT WIRE
RED WIRE
RED/WHT WIRE
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.3l vin t (2 of 5) -> F/PMP RELAY 35
