Chevrolet SSR I (2003-2006) folding top outer latch actuator ctrl ground Wiring diagram
This page shows the only wiring diagram for the component.folding top outer latch actuator ctrl ground, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram folding top outer latch actuator ctrl ground (1 of 1)
BATTERY POSITIVE VOLTAGE
BLK WIRE
DK BLU WIRE
DK GRN WIRE
FOLD TOP OUTER LATCH ACTUATOR CTRL
FOLDING TOP MOTOR LEFT RELAY (NEAR ROOF/ DOOR MODULE)
FOLDING TOP MOTOR RIGHT RELAY (NEAR ROOF/DOOR MODULE)
FOLDING TOP OUTER LATCH ACTUATOR (CENTER OF, ABOVE INSIDE REARVIEW MIRROR)
FOLDING TOP OUTER LATCH ACTUATOR CTRL GROUND
FOLDING TOP PUMP MOTOR
FOLDING TOP PUMP MOTOR ASSEMBLY (IN CENTER BOTTOM OF ROOF STOWAGE COMPT)
FOLDING TOP VALVE 1 CONTROL
FOLDING TOP VALVE 2 CONTROL
FOLDING TOP VALVE 3 CONTROL
FOLDING TOP VALVE 4 CONTROL
FOLDING TOP VALVE 4 CRTL
FUSE 28
HOT AT ALL TIMES
HOT IN RUN, START, ACC
IGN 0 FUSE 47
LT BLU WIRE
LT GRN WIRE
NCA WIRE
NTC THEMISTOR
ORG/ WIRE
PNK WIRE
PPL
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RED WIRE
RED/GRN WIRE
ROOF DOOR MOD CIRCUIT BEAKER 1
ROOF-PUMP CIRCUIT BREAKER 2
ROOF/DOOR MODULE (REAR CENTER OF PASSENGER COMPARTMENT)
WHT WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> FOLDING TOP OUTER LATCH ACTUATOR CTRL GROUND
