Chevrolet SSR I (2003-2006) fold top stowage lid latch sig Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 (PIN 15-24 NOT USED) A/T SHIFT LOCK SOLENOID AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH ASSEMBLY DK BLU WIRE DK BLU/WHT (OR LT BLU) WIRE DK GRN/WHT WIRE EXTENDED FOLD TOP OUTER STRIKER OVER CENTER SIG FOLD TOP OUTER STRIKER SW DISENGAGE SIG FOLD TOP STOWAGE LID LATCH SIG FOLDING TOP CYLINDER POSITION SENSOR (BEHIND RIGHT "B" PILLAR) FOLDING TOP OUTER LATCH POSITION SWITCH (IN HEADER, ABOVE LEFT VISOR) FOLDING TOP SW UP SIG FOLDING TOP SW DOWN SIG FOLDING TOP SWITCH GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE LATCHED RELEASED LEFT FOLDING TOP STOWAGE COMPARTMENT LID CYLINDER POSITION SENSOR LEFT FRONT DOOR AFAR SW SIG LEFT FRONT DOOR HANDLE SW SIG LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE OVER CENTER DISENGAGED POWER WINDOWS SYSTEM PPL REAR COMPT LID RELEASE SIG REAR COMPT LID AJAR SIG RED WIRE RETRACTED RIGHT FOLDING TOP STOWAGE COMPARTMENT LID CYLINDER POSITION SENSOR RIGHT FRONT DOOR AJAR SW SIG RIGHT FRONT HANDLE SW SIG ROOF EXTENDED ROOF RETRACTED ROOF/DOOR MODULE (REAR CENTER OF PASSENGER COMPARTMENT) TAN WIRE TRUCK/TAILGATE FUEL DOORS SYSTEM UP DOWN WHT WIRE YEL WIRE
