Chevrolet SSR I (2003-2006) fog lmp rly hi bm rly ctrl drl rly ctrl low bm rly ctrl clss 2 ser data Wiring diagram

AMBIENT LIGHT SENSOR (TOP CENTER OF DASH) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (NEAR REAR RELAY BLOCK) CLASS 2 SER DATA COILS FUSE 4 COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRL DIODE DRL FUSE 13 FLASH TO PASS HI BEAM FOG LAMP IND FOG LAMP SWITCH FOG LMP RLY HI BM RLY CTRL DRL RLY CTRL LOW BM RLY CTRL CLSS 2 SER DATA FOG LMPS ENABLE HDLMP DIM SW FOG LP FUSE 11 FOG LP RELAY 36 FTP SIG GRN WIRE GRY WIRE GRY/BLK WIRE HDLMP ON SIG HDLP HI RELAY 37 HDM RELAY 41 HEAD HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HIGH BEAM IND HOT AT ALL TIMES IGN IPC CLASS 2 SER DATA INSTRUMENT PANEL CLUSTER LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP LEFT HIGH BEAM HEAD- LAMP LEFT LOW BEAM HEAD- LAMP LOW BEAM LOW REF LT DRL RELAY LT GRN WIRE LT GRN/BLK WIRE LT HI HDLP FUSE 7 LT LOW HDLP FUSE 11 OFF AUTO ORG/ WIRE PARK PNK WIRE PNK/WHT WIRE PPL PPL PPL PRK LMPS ON SIG REAR FUSE BLOCK REAR RELAY BLOCK (REAR CENTER OF PASSENGER COMPT) RIGHT HIGH BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP RT DRL RELAY RT HI HDLP FUSE 8 RT LOW HDLP FUSE 12 SEN SIG TAN WIRE TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENG COMPT) WHT WIRE YEL WIRE
