Chevrolet SSR I (2003-2006) fan rly ctrl serial data serial data ect sens sig low ref Wiring diagram
This page shows the only wiring diagram for the component.fan rly ctrl serial data serial data ect sens sig low ref, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fan rly ctrl serial data serial data ect sens sig low ref (1 of 1)
4 5 6137 2218 A/C REQ SIG SERIAL DATA
A/C REFRIGERANT PRESSURE SENSOR (RIGHT FRONT STRUT TOWER)
AIR TEMPERATURE ACTUATOR (BEHIND RADIO, TOP OF HVAC CASE)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/BLK WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT FRONT OF ENGINE)
EVAPORATOR TEMPERATURE SENSOR (ON TOP OF HVAC CASE)
FAN RLY CTRL SERIAL DATA SERIAL DATA ECT SENS SIG LOW REF
GRY WIRE
LT BLU WIRE
LT GRN/BLK WIRE
MODE ACTUATOR (LEFT SIDE OF DASH, ON HVAC CASE)
NCA WIRE
ORG/ WIRE
PNK 1 2 3 WIRE
PNK WIRE
PNK/WHT WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT FRONT SIDE OF ENGINE COMPT)
RECIRCULATION ACTUATOR (ABOVE BLOWER MOTOR)
RED/BLK WIRE
ROOF/DOOR MODULE (REAR CENTER OF PASS COMPT)
SENS SIG LOW REF FAN RLY CTRL CL RLY CTRL
WHT/BLK WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> FAN RLY CTRL SERIAL DATA SERIAL DATA ECT SENS SIG LOW REF
