Chevrolet SSR I (2003-2006) driver passenger off Wiring diagram
This page shows the only wiring diagram for the component.driver passenger off, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver passenger off (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DDM FUSE 10
DOWN
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER PASSENGER OFF
GRN WIRE
HORIZONTAL
HOT AT ALL TIMES
LEFT
LT LT
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RED WIRE
RIGHT
VERTICAL
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> DRIVER PASSENGER OFF
