Chevrolet SSR I (2003-2006) driver belt switch Wiring diagram
This page shows the only wiring diagram for the component.driver belt switch, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver belt switch (1 of 1)
3 11 LEFT SEAT BELT SW LOW REF
AJAR
AJAR ASSEMBLY
BCM CLASS 2 SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (REAR CENTER OF PASS COMPT, NEAR REAR RELAY BLOCK)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER BELT SWITCH
DRIVER DOOR AJAR PASSENGER DOOR AJAR
DRIVER DOOR LATCH ASSEMBLY
GRY WIRE
GRY/BLK WIRE
HEAD
HEADLAMP SWITCH
HEADLAMPS ON SIG
IGN
IGNITION KEY ALARM SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
IPC CLASS 2 SERIAL DATA
KEY IN IGN SW SIG
LF DR AJAR SWITCH SIG
LOGIC
LT GRN WIRE
MESSAGE CENTER
OFF/AUTO PARK
PARK LAMP SWITCH SIG
PASSENGER DOOR LATCH
REAR FUSE BLOCK (REAR CENTER OF PASS COMPT)
RF DR AJAR SWITCH SIG
SEAT BELT IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TAN WIRE
WHT WIRE
Go to component -> Warning systems circuit -> DRIVER BELT SWITCH
