Chevrolet SSR I (2003-2006) center high mounted stop lamp rear compartment ajar switch Wiring diagram
This page shows the only wiring diagram for the component.center high mounted stop lamp rear compartment ajar switch, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center high mounted stop lamp rear compartment ajar switch (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM)
CENTER HIGH MOUNTED STOP LAMP REAR COMPARTMENT AJAR SWITCH
COOLING FAN
DATA LINK CONNECTOR
HAZARD LAMP SWITCH
HEADLAMP DIMMER SWITCH
HORN ASSEMBLY
IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 4 IGNITION COIL 2
IGNITION COIL 5
IGNITION COIL 6
IGNITION COIL 7
IGNITION COIL 8
IGNITION KEY ALARM SWITCH
INFLATABLE RESTRAINT I/P MODULE DISABLE SWITCH
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT LICENSE LAMP
LEFT REAR MARKER LAMP LEFT BACKUP LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
RADIO
REAR AUXILIARY POWER OUTLET
REAR COMPARTMENT LID LAMP
REAR COMPARTMENT LID RELEASE SWITCH/ ACTUATOR REAR COMPARTMENT PRESENT SWITCH
REMOTE CONTROL DOOR LOCK RECEIVER
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LICENSE LAMP
RIGHT LOW BEAM HEADLAMP RIGHT FRONT FOG LAMP
RIGHT REAR MARKER LAMP RIGHT BACKUP LAMP
RIGHT TAIL/STOP, TURN SIGNAL LAMP
TAN WIRE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR MODULE
WINDSHIELD WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (3 of 3) -> CENTER HIGH MOUNTED STOP LAMP REAR COMPARTMENT AJAR SWITCH
