Chevrolet SSR I (2003-2006) antenna enable illum dim ctrl grd Wiring diagram
This page shows the only wiring diagram for the component.antenna enable illum dim ctrl grd, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram antenna enable illum dim ctrl grd (1 of 1)
AM/FM ANTENNA
ANTENNA
ANTENNA ENABLE ILLUM DIM CTRL GRD
ANTENNA ENABLE SIGNAL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER SPEAKER
LEFT REAR SPEAKER
LF SPKR OUT + LF SPKR OUT - RR SPKR OUT - RR SPKR OUT + SIG GND
LR SPKR OUT + LR SPKR OUT - RF SPKR OUT - RF SPKR OUT +
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
RADIO
RADIO ANTENNA MODULE (TOP CENTER OF WINDSHIELD
RDO FUSE 41
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER SPEAKER
RIGHT REAR DOOR SPEAKER
SERIAL DATA
TAN WIRE
YEL WIRE
Go to component -> Base radio circuit -> ANTENNA ENABLE ILLUM DIM CTRL GRD
