Chevrolet SSR I (2003-2006) 14 13 rr compt lid ajar sw sig rr compt lid rel sw sig wiring diagram
This page shows the only wiring diagram for the component.14 13 rr compt lid ajar sw sig rr compt lid rel sw sig, which is found in the car Chevrolet SSR I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
14 13 rr compt lid ajar sw sig rr compt lid rel sw sig wiring diagram (1 of 1)
14 13 RR COMPT LID AJAR SW SIG RR COMPT LID REL SW SIG
5 7 BATTERY BATTERY
BED COVER RELEASE FUSE 31
BEDCOVER RELEASE RELAY 38
BLK WIRE
BRN WIRE
EXTERIOR REAR COMPARTMENT LID RELEASE SWITCH/ACTUATOR
GRN WIRE
HOT AT ALL TIMES
INTERIOR REAR COMPARTMENT LID RELEASE SWITCH
LT GRN WIRE
NCA WIRE
ORG/ WIRE
RDM 2 FUSE 28
REAR COMPARTMENT AJAR SWITCH
REAR COMPARTMENT PRESENT SWITCH
REAR FUSE BLOCK
REAR FUSE BLOCK (REAR CENTER OF PASSENGER COMPT)
RED WIRE
RED/BLK WIRE
ROOF/DOOR CB 1
ROOF/DOOR MODULE (REAR CENTER OF PASSENGER COMPT)
RR COMPT LID REL RLY CTRL
RR COMPT PRESENT SW SIG
SPLICE PACK
TAN WIRE
UNDER- HOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
