Chevrolet Sportvan G30 (1985-1994) Instrument cluster circuit, cutaway chassis

0.5 WATT) AUDIO ALARM MODULE CONVENIENCE CENTER BLK WIRE BLK/YEL WIRE BLU WIRE BRAKE IND BRAKE PRESSURE WARNING SWITCH (ON LEFT FRAME RAIL) IGNITION SWITCH BRAKE WARNING ALARM BUZZER (BEHIND LEFT SIDE OF I/P, NEAR FUSE BLOCK) BRN/WHT WIRE COOLANT TEMP COOLANT TEMP GAUGE DAYTIME RUNNING LAMPS IND DAYTIME RUNNING LAMPS MODULE DAYTIME RUNNING LAMPS RELAY DK BLU WIRE DK GRN WIRE ELECTRONIC DELAY MODULE (BEHIND LEFT SIDE OF I/P, ON PARK BRAKE SUPPORT BRACKET) ENGINE COOLANT TEMPERATURE SENSOR FLOW SWITCH (NEAR POWER STEERING PUMP) FUEL GAUGE FUEL LEVEL FUSE BLOCK INSTR LPS FUSE GAGES FUSE GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HI-BEAM IND HOT IN RUN, BULB TEST OR START HOT W/ LAMP SWITCH IN PARK OR HEAD HYDRO-BOOST PRESSURE WARNING SWITCH (NEAR MASTER CYLINDER) IGN ILLUM ILLUM LAMP ILLUM. LAMPS IN-LINE DIODE (BEHIND LEFT SIDE OF I/P, ABOVE FUSE BLOCK) IN-LINE DIODE (BEHIND LEFT SIDE OF I/P, ABOVE STEERING COLUMN) INSTRUMENT CLUSTER LEFT TURN IND LOW COOLANT IND LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE MAL- FUNCTION IND OIL PRESS GAUGE OIL PRESS. SIGNAL PARK BRAKE WARNING SWITCH W/ DRL PNK PNK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (UNDER DRIVER'S SEAT) PPL RESISTOR RIGHT TURN IND SAFETY BELT IND SPEED- OMETER TAN WIRE TAN/WHT WIRE VEHICLE SPEED VOLT- METER W/ DRL W/ DRL PPL W/O DRL WHT WIRE YEL WIRE
