4.3l (vin z), transmission circuit, 4l80-e for Chevrolet Sportvan G20 (1985-1995)

2-3 SHIFT SOL 3-2 SOL 1-2 SHIFT SOL BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK BLU WIRE DK BLU/WHT WIRE ECM I FUSE ECM-B FUSE ENGINE COOLANT TEMPERATURE (ECT) SENSOR (TOP FRONT OF ENGINE) GAGES FUSE GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (PCM) (RIGHT KICK PANEL) PPL PPL/WHT WIRE PRESSURE CONTROL SOLENOID RANGE MODE SELECTOR RED WIRE RED/BLK WIRE SERVICE ENGINE SOON INDIC SPEED SENSOR (LEFT REAR SIDE OF TRANSMISSION) TAN WIRE TAN/WHT WIRE TCC/STOPLAMP SWITCH (ON BRAKE PEDAL BRACKET) THROTTLE POSITION SENSOR (RIGHT SIDE OF TBI) TRANS FLUID TEMP (TFT) SENSOR TRANS FUSE TRANSMISSION TRANSMISSION INPUT SHAFT SPEED SENSOR (FRONT OF TRANSMISSION) VEHICLE SPEED SENSOR BUFFER (PARKING BRAKE SUPPORT BRACKET) WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
