Chevrolet Sportvan G20 (1985-1995) knock sensor signal Wiring diagram

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE DATA LINK CONNECTOR (BEHIND LEFT SIDE OF SHIPPING PANEL) DIAGNOSIS TEST TP SIGNAL INJECTOR 1 CTRL DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM BAT FUSE ECM-CRNK FUSE ECT SIGNAL EGR CONTROL ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE) ENGINE GROUND FUEL PUMP RELAY CTRL FUEL PUMP SIGNAL MAP SIGNAL FUSE BLOCK GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START IC BYPASS TP/ECT GROUND MAP GROUND IC SIGNAL VSS SIGNAL VSS TP REFERENCE IDLE AIR CONTROL ACTUATOR (TOP REAR OF ENGINE) INJ FUSE KNOCK SENSOR SIGNAL LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MANIFOLD ABSOLUTE PRESSURE SENSOR (TOP REAR OF ENGINE) MAP REFERENCE IGNITION FUSED BATTERY FEED ORG/ WIRE ORG/BLK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (LEFT SIDE OF SHIPPING PANEL) PPL PPL 3 4 PPL/WHT WIRE RED WIRE SERIAL DATA TAN WIRE TAN/BLK WIRE TAN/WHT WIRE THROTTLE BODY FUEL INJECTOR #1 (TOP OF THROTTLE BODY UNIT) THROTTLE BODY FUEL INJECTOR #2 (TOP OF THROTTLE BODY UNIT) THROTTLE POSITION SENSOR (TOP RIGHT SIDE OF ENGINE) WHT WIRE WHT/BLK WIRE YEL WIRE
