Chevrolet Spark M400 facelift (2018-2024) sens low Wiring diagram
This page shows the only wiring diagram for the component.sens low, which is found in the car Chevrolet Spark M400 facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens low (1 of 1)
A/T
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRK POSITION
BRK POSITION SENS
CENTER HIGH MOUNTED STOP LAMP
CLUTCH PEDAL POSITION SENSOR
COMPUTER DATA LINES SYSTEM
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HI SPD GMLAN
LEFT BACKUP LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAIL/ STOP LAMP
M/T
NCA WIRE
REF, CLTH APPLY
RIGHT BACKUP LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAIL/ STOP LAMP
SENS LOW
SER DATA (-) (1)
SIG, CLTH APPLY
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
VIO/WHT WIRE
W/ FRONT SIDE REFLEX MARKER LAMP
W/ LED
W/O FRONT SIDE REFLEX MARKER LAMP
W/O LED
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> SENS LOW
