Chevrolet Spark M400 facelift (2018-2024) rear right outer parking assist sensor Wiring diagram
This page shows the only wiring diagram for the component.rear right outer parking assist sensor, which is found in the car Chevrolet Spark M400 facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear right outer parking assist sensor (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LO SPD GMLAN SER DATA
LOGIC
LR CORNER OBJECT SENS SIG
LR MIDDLE OBJECT SENS SIG
OBJECT SENS CTRL
OBJECT SENS LOW REF
PARKING ASSIST CONTROL MODULE
PARKING ASSIST IND
REAR LEFT OUTER PARKING ASSIST SENSOR
REAR MIDDLE PARKING ASSIST SENSOR
REAR RIGHT OUTER PARKING ASSIST SENSOR
RED/BLU WIRE
RR CORNER OBJECT SENS SIG
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Parking assistant circuit -> REAR RIGHT OUTER PARKING ASSIST SENSOR
