Chevrolet Spark M400 facelift (2018-2024) onstar switch Wiring diagram
This page shows the only wiring diagram for the component.onstar switch, which is found in the car Chevrolet Spark M400 facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram onstar switch (1 of 1)
BATTERY POSITIVE VOLT
BLK WIRE
BRN/WHT WIRE
EMERGENCY SWITCH
GREEN IND
GRN/BLK WIRE
GRN/WHT WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSIDE REAR VIEW MIRROR
INSTRUMENT PANEL FUSE BLOCK
KEYPAD
KEYPAD CTRL
KEYPAD GREEN LED CTRL
KEYPAD SIG
ONSTAR SWITCH
PHONE SWITCH
RED LED CTRL WIRE
RED/YEL WIRE
TELEMATICS BUTTON ASSEMBLY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
YEL/VIO WIRE
Go to component -> Electrochromic mirror circuit -> ONSTAR SWITCH
