Chevrolet Spark M400 (2015-2024) w/o rear door power window Wiring diagram
This page shows the only wiring diagram for the component.w/o rear door power window, which is found in the car Chevrolet Spark M400 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o rear door power window (1 of 1)
A/C COMPRESSOR CLUTCH
BACKUP LAMP SWITCH
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
CVT
DRIVER BACK SEAT HEATING ELEMENT
DRIVER CUSHION SEAT HEATING ELEMENT
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK KEY CYLINDER SWITCH
DRIVER DOOR LOCK SWITCH
DRIVER EXTERIOR DOOR HANDLE ASSEMBLY
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
ENGINE CONTROL MODULE
FRONT DOME/ READING LAMPS
FUEL PUMP RELAY
IGNITION MAIN RELAY
INSIDE REAR VIEW MIRROR
LEFT TURN SIGNAL REPEATER LAMP
M/T
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
OUTSIDE REAR VIEW MIRROR SWITCH
PARK/ NEUTRAL POSITION SWITCH
PASSENGER AIR BAG DISABLED INDICATOR
PRIMARY TRANSMISSION PULLEY SPEED SENSOR
REAR DEFOGGER RELAY
REAR WINDOW WASHER PUMP RELAY
REAR WIPER RELAY
SECONDARY TRANSMISSION PULLEY SPEED SENSOR
STARTER RELAY
SUNROOF CONTROL MODULE
TRANSMISSION CONTROL MODULE
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
W/ EXPRESS UP/DOWN
W/ FORWARD COLLISION ALERT, LANE DEPARTURE WARNING
W/ FRONT HEATED SEATS
W/ REAR DOOR POWER WINDOW
W/O REAR DOOR POWER WINDOW
WINDSHIELD FRONT VIEW CAMERA
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (3 of 5) -> W/O REAR DOOR POWER WINDOW
