Chevrolet Spark M400 (2015-2024) transmission ctrl module clutch solenoid enable a wiring diagram
This page shows the only wiring diagram for the component.transmission ctrl module clutch solenoid enable a, which is found in the car Chevrolet Spark M400 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
transmission ctrl module clutch solenoid enable a wiring diagram (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SENSOR
BRN/RED WIRE
CLUTCH PEDAL POSITION SENSOR
COMPUTER DATA LINES SYSTEM
CRUISE IND
CVT
DRIVER INFORMATION CENTER DISPLAY
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/RED WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
INSTRUMENT CLUSTER
LOGIC
M/T
PRIMARY TRANSMISSION PULLEY SPEED SENSOR
SECONDARY TRANSMISSION PULLEY SPEED SENSOR
SERIAL DATA
TRANSMISSION CONTROL MODULE
TRANSMISSION CTRL MODULE CLUTCH SOLENOID ENABLE A
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
TRANSMISSION SPD SENS SIG
VEHICLE SPD SENS SIG
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit (2 of 2) -> TRANSMISSION CTRL MODULE CLUTCH SOLENOID ENABLE A
