Chevrolet Spark M400 (2015-2024) rr compt lid lp ctrl Wiring diagram
This page shows the only wiring diagram for the component.rr compt lid lp ctrl, which is found in the car Chevrolet Spark M400 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr compt lid lp ctrl (1 of 1)
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DRIVER DOOR AJAR SWITCH
DRIVER INFORMATION CENTER DISPLAY
FRONT DOME/READING LAMPS
GRN WIRE
GRN/GRY WIRE
GRY WIRE
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INTERIOR LP CTRL
LEFT "C" PILLAR)
LEFT REAR DOOR AJAR SWITCH
LF DR AJAR SW SIG
LOGIC
LOW SPD GMLAN SER DATA
LR DR AJAR SW SIG
PASSENGER DOOR AJAR SWITCH
REAR COMPARTMENT COURTESY LAMP
RED/BLU WIRE
RED/GRY WIRE
RF DR AJAR SW SIG
RIGHT REAR DOOR AJAR SWITCH
RR COMPT LID LP CTRL
RR DR AJAR SW SIG
W/ EXPRESS UP/DOWN
WHT/BRN WIRE
Go to component -> Courtesy lamps circuit -> RR COMPT LID LP CTRL
