Chevrolet Spark M400 (2015-2024) grn Wiring diagrams

ALERT LED CTRL BATT POS VOLT BLK WIRE BLU WIRE BODY CONTROL MODULE COLLISION ALERT INDICATORS COMM ENABLE COMPUTER DATA LINES SYSTEM DISABLE GRN WIRE GRY/WHT WIRE GRY/YEL WIRE HI SPD GMLAN SER DATA (+) 1 HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED IGN 1 VOLT INDICATOR DIMMING CTRL INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL MULTI- FUNCTION SWITCH LANE DEPARTURE WARNING DISABLE LANE DEPARTURE WARNING DISABLE SWITCH LANE DEPARTURE WARNING IND LANE DEPARTURE WARNING IND CTRL LED DISPLAY DIMMING CONTROL LEFT STEERING WHEEL CONTROLS SWITCH LO SPD GMLAN SER DATA LOGIC RED/WHT WIRE RED/YEL WIRE STEERING WHEEL AIR BAG COIL SW SIG VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WINDSHIELD FRONT VIEW CAMERA

BATT POS VOLT BLK WIRE BLK/GRY WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LO SPD GMLAN SER DATA LOGIC LR CORNER OBJECT SENS SIG LR MIDDLE OBJECT SENS SIG OBJECT SENS CTRL OBJECT SENS LOW REF PARKING ASSIST CONTROL MODULE PARKING ASSIST IND REAR LEFT OUTER PARKING ASSIST SENSOR REAR MIDDLE PARKING ASSIST SENSOR REAR RIGHT OUTER PARKING ASSIST SENSOR RED/BLU WIRE RR CORNER OBJECT SENS SIG YEL WIRE YEL/BLU WIRE YEL/VIO WIRE

A/C REFRIGERANT PRESS SENS LOW REF A/C REFRIGERANT PRESS SENS SIG A/C REFRIGERANT PRESSURE SENSOR ACC PEDAL POS LOW REF (2) ACCELERATOR PEDAL POSITION SENSOR ACCESSORY WAKEUP SER DATA BATTERY FUSE BLOCK BATTERY POSITIVE VOLT BLK/BLU WIRE BLK/BRN WIRE BLK/VIO WIRE BLU WIRE BRN/RED WIRE BRN/WHT WIRE CHECK ENGINE INDICATOR CTRL COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM CRUISE/ETC/TCC BRAKE SIG ENGINE CONTROL MODULE ENGINE OIL PRESSURE CONTROL SOLENOID VALVE EVAP CANISTER VENT SOLENOID CTRL EVAPORATIVE EMISSION VENT SOLENOID VALVE FUEL PUMP PRIMARY RLY CTRL GRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY/BLK WIRE HI SPD GMLAN SER DATA (+) 1 HOT AT ALL TIMES M/T MASS AIR FLOW SENS SIG OIL PUMP COMMAND SIG OUTPUT SPD (DIGITAL) SENS LOW REF OUTPUT SPD DIGITAL SIG POWERTRAIN MAIN RLY FUSED SPLY 1 POWERTRAIN MAIN RLY FUSED SPLY 4 POWERTRAIN RLY COIL CTRL RED/GRY WIRE RED/WHT WIRE RUN/CRANK IGNITION 1 VOLT STARTER ENABLE RLY CTRL STARTING/CHARGING SYSTEM THROTTLE INLET ABSOLUTE PRESS SENS LOW REF ACC PEDAL POS SIG 2 TRANS PARK/NEUTRAL SIG 1 VEHICLE SPEED SENSOR VIO/BLU WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/VIO WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SENSOR BRN/GRY WIRE BRN/WHT WIRE CLUTCH PEDAL POSITION SENSOR COMPUTER DATA LINES SYSTEM CRANKSHAFT POSITION SENSOR CVT DRIVER INFORMATION CENTER DISPLAY ENGINE OIL IND EVAPORATIVE EMISSION PURGE SOLENOID VALVE FUEL GAUGE FUEL LEVEL SENSOR FUEL PUMP FUEL PUMP, LEVEL SENSOR ASSEMBLY FUEL TANK PRESSURE SENSOR GRN WIRE GRN/BLU WIRE GROUND GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN SENSOR 1 HEATED OXYGEN SENSOR 2 HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK INTAKE CAMSHAFT POSITION SENSOR LOGIC LOW SPD GMLAN SER DATA M/T MALFUNCTION IND NCA WIRE RUN/CRANK IGNITION 1 VOLT UNDERHOOD FUSE BLOCK VIO/BLU WIRE VIO/GRY WIRE W/ FRONT SIDE REFLEX MARKER LAMP W/O FRONT SIDE REFLEX MARKER LAMP WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE

BANK 1 SENS 1 BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CAMSHAFT POS EXHAUST CAMSHAFT POS INTAKE CHARGE INDICATOR CTRL CHARGING DUTY CYCLE SIG ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT, NEAR BATTERY) EVAP CANISTER EXHAUST CAMSHAFT POSITION SENSOR FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR CTRL 1 FUEL INJECTOR CTRL 2 FUEL INJECTOR CTRL 3 FUEL INJECTOR CTRL 4 FUEL TANK PRESS SENS SIG GENERATOR FIELD GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEATED OXYGEN SENS HEATED OXYGEN SENS HEATER HEATER LOW CTRL IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LOW CTRL BANK 1 SENS 2 MANIFOLD ABSOLUTE NCA WIRE OIL PRESS SENS LOW REF OIL PRESS SENS SIG PLUG PRESS SENS LOW REF PURGE SOLENOID CTRL SENS CTRL 1 SENS SPLY VOLT (1) SPARK STARTING/ SYSTEM VIO/BLK WIRE VIO/BLU WIRE VIO/GRY WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/VIO WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CAM PHASER W LOW REF CAM PHASER X LOW REF CAMSHAFT PHASER EXHAUST SOLENOID 1 CAMSHAFT PHASER INTAKE SOLENOID 1 CAMSHAFT POS EXHAUST SENS 1 CAMSHAFT POS EXHAUST SENS LOW REF 1 CAMSHAFT POS INTAKE SENS LOW REF 1 CAMSHAFT POSITION INTAKE SENS 1 COOLANT TEMP SENS LOW REF ENGINE CONTROL MODULE ENGINE COOLANT HEATER ENGINE COOLANT HEATER CABLE ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SENSOR EXHAUST CAMSHAFT POSITION ACTUATOR SOLENOID VALVE GRN WIRE GRN/BLU WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/RED WIRE HEATED OXYGEN SENS LOW SIG BANK 1 SENS 1 HEATED OXYGEN SENS LOW SIG BANK 1 SENS 2 HUMIDITY SENS SIG IGNITION CTRL 1 IGNITION CTRL 2 IGNITION CTRL 3 IGNITION CTRL 4 IGNITION CTRL LOW REF BANK 1 INTAKE CAMSHAFT POSITION ACTUATOR SOLENOID VALVE KNOCK SENS SIG 1 KNOCK SENSOR KNOCK SENSOR LOW REF 1 MANIFOLD ABSOLUTE PRESSURE SENSOR PWR REVERSE SWITCH SIG THROTTLE ACTUATOR CONTROL OPEN THROTTLE ACTUATOR CTRL CLOSE THROTTLE POS SENS LOW REF VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/VIO WIRE
