Chevrolet Spark M400 (2015-2024) clutch solenoid enable a sw parity bit sig wiring diagram
This page shows the only wiring diagram for the component.clutch solenoid enable a sw parity bit sig, which is found in the car Chevrolet Spark M400 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
clutch solenoid enable a sw parity bit sig wiring diagram (1 of 1)
BACKUP LAMP SWITCH
BATT POS VOLT
BKUP LP SPLY VOLT
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
CLUTCH SOLENOID ENABLE A SW PARITY BIT SIG
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
HI SPD GMLAN SER DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT BACKUP LAMP
LEFT TAIL LAMP ASSEMBLY
MODE SIG
NCA WIRE
PARK/NEUTRAL POSITION SWITCH
REAR VIEW CAMERA
RED/BLU WIRE
REVERSE SW SIG
RIGHT BACKUP LAMP
RIGHT TAIL LAMP ASSEMBLY
SW BIT 2 SIG
SW BIT 3 SIG
SW BIT 4 SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION CONTROL MODULE RELAY
UNDERHOOD FUSE BLOCK
VIO/GRN WIRE
W/ FRONT SIDE REFLEX MARKER LAMP
W/O FRONT SIDE REFLEX MARKER LAMP
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Backup lamps circuit -> CLUTCH SOLENOID ENABLE A SW PARITY BIT SIG
