Chevrolet Spark M400 (2015-2024) ajar sw sig Wiring diagram
This page shows the only wiring diagram for the component.ajar sw sig, which is found in the car Chevrolet Spark M400 (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ajar sw sig (1 of 1)
AJAR SW SIG
BLK WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/YEL WIRE
BUS 4
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOWN EXPRESS
DOWN SIG
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
EXPRESS SIG
GRN WIRE
GRN/BLK WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ RETAINED ACCESSORY POWER RELAY 1 ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LIN NETWORK
LOGIC
PASSENGER WINDOW MOTOR
PASSENGER WINDOW SWITCH
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
UP SIG
VIO/YEL WIRE
WHT WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Power windows circuit, w/ express up/down -> AJAR SW SIG
