Chevrolet Spark M300 facelift (2016-2024) set/coast/resume/ acc sw sig wiring diagram

5-VOLT REF 1 ACCELERATOR PEDAL POSITION (APP) SENSOR APP 2 5-V REF APP LOW REF 1 APP LOW REF 2 APP SENS SIG (2) APP SENS SIG 1 BATT POSTIVE VOL BATTERY POSITIVE VOLTAGE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BODY CONTROL MODULE (PASSENGER COMPT INSTRUMENT PANEL) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK APPLY SENS SIG BRK SENS SUPPLY VOLT BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRUISE IND CRUISE SWITCH CRUISE/ETC/TCC BRK SIG DRIVER INFORMATION CENTER DISPLAY ECM/ TCM 1 FUSE ECM/TCM 2 FUSE ENGINE CONTROL MODULE (ECM) GRN WIRE GRN/WHT WIRE GROUND GRY/BLK WIRE GRY/RED WIRE HI SPD GMLAN HI SPD GMLAN DATA (+) HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT CLUSTER LEFT STEERING WHEEL CONTROLS SWITCH LOGIC LOW REF RED/BLU WIRE RED/BRN WIRE RES+ SENS SIG SET- SET/COAST/RESUME/ ACC SW SIG SOUND SYSTEMS SPLY VOL STEERING WHEEL AIR BAG COIL TA CTRL CLOSE TA CTRL OPN THROTTLE BODY (ON INTAKE MANIFOLD) TP SENS 5 VOLT REF TP SENS LOW REF TP SENS SIG 1 TP SENS SIG 2 TRANSMISSION CONTROL MODULE TRANSMISSION INPUT SHAFT SPEED SENSOR TRANSMISSION OUTPUT SHAFT SPEED SENSOR TSS SIG UNDERHOOD FUSE BLOCK VEHICLE SPEED SENSOR VIO/GRN WIRE VIO/WHT WIRE VOLTAGE SENSING FUSE VSS SIG WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/VIO WIRE YEL/WHT WIRE
