Chevrolet Spark M300 facelift (2016-2024) outside ambient air temp sensor signal Wiring diagram
This page shows the only wiring diagram for the component.outside ambient air temp sensor signal, which is found in the car Chevrolet Spark M300 facelift (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside ambient air temp sensor signal (1 of 1)
"CHECK ENGINE" IND CTRL
ABS IND.
ADJUSTABLE WARNING IND
AIR BAG IND
AMBIENT AIR TEMPERATURE SENSOR
BATT POSITIVE VOLT
BLK WIRE
BLK/BLU WIRE
BLU/GRY WIRE
BRAKE WARNING IND
BRN WIRE
BRN/WHT WIRE
CHARGING IND
COMPUTER DATA LINES SYSTEM
CRUISE IND
DOOR AJAR IND
DRIVER INFORMATION CENTER DISPLAY
DRL IND
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE IND
ENGINE OIL LEVEL IND
FRONT FOG LAMP IND
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HEADLAMPS ON IND
HIGH BEAM IND
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
ILLUMINATION IND
INFORMATION DISPLAY CIRCUIT
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IPC FUSE
IPC I/P IND FUSE
LEFT TURN SIG IND
LO SPD GMLAN SERIAL DATA
LOGIC
LOW FUEL WARNING LAMP IND
LOW TIRE PRESSURE IND
MALFUNCTION IND
OUTSIDE AMBIENT AIR TEMP SENSOR SIGNAL
OUTSIDE AMBIENT TEMP SENS LO REF
PARK LAMP IND
PARKING ASSIST IND
POWER STEERING WARNING IND
REAR FOG LAMP IND
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
REDUCED ENGINE POWER IND
RIGHT SIDE OF FRONT GRILLE)
RIGHT TURN SIG IND
RUN/CRANK IGN 1 VOLT
SEAT BELT IND
SECURITY IND
SPEEDOMETER
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
VOLTAGE SENSING FUSE
Go to component -> Instrument cluster circuit (1 of 2) -> OUTSIDE AMBIENT AIR TEMP SENSOR SIGNAL
